Bonjour @cstan77
Les voici :
{
"ieee": "84:fd:27:ff:fe:b7:c0:57",
"nwk": 60452,
"status": 2,
"lqi": "255",
"rssi": "-74",
"last_seen": "1639580042.4595716",
"node_descriptor": "02:40:80:02:10:52:52:00:00:2c:52:00:00",
"endpoints": [
{
"id": 1,
"status": 1,
"device_type": 769,
"profile_id": 260,
"manufacturer": "_TZE200_b6wax7g0",
"model": "TS0601",
"output_clusters": [
{
"id": 10,
"name": "Time",
"attributes": []
},
{
"id": 25,
"name": "Ota",
"attributes": []
}
],
"input_clusters": [
{
"id": 0,
"name": "Basic",
"attributes": [
{
"id": 0,
"name": "zcl_version",
"value": 3
},
{
"id": 1,
"name": "app_version",
"value": 64
},
{
"id": 2,
"name": "stack_version",
"value": 0
},
{
"id": 3,
"name": "hw_version",
"value": 1
},
{
"id": 4,
"name": "manufacturer",
"value": "_TZE200_b6wax7g0"
},
{
"id": 5,
"name": "model",
"value": "TS0601"
},
{
"id": 6,
"name": "date_code",
"value": ""
},
{
"id": 7,
"name": "power_source",
"value": 3
}
]
},
{
"id": 4,
"name": "Groups",
"attributes": []
},
{
"id": 5,
"name": "Scenes",
"attributes": []
},
{
"id": 61184,
"name": "Tuya Manufacturer Specicific",
"attributes": [
{
"id": 621,
"name": "valve_state",
"value": 5
},
{
"id": 514,
"name": "target_temperature",
"value": 20
},
{
"id": 515,
"name": "temperature",
"value": 190
},
{
"id": 615,
"name": "max_temperature",
"value": 300
},
{
"id": 617,
"name": "boost_duration_seconds",
"value": 4294967294
},
{
"id": 619,
"name": "comfort_mode_temperature",
"value": 2
},
{
"id": 620,
"name": "eco_mode_temperature",
"value": 28
}
]
},
{
"id": 513,
"name": "MoesThermostatNew",
"attributes": [
{
"id": 0,
"name": "local_temp",
"value": 1900
},
{
"id": 18,
"name": "occupied_heating_setpoint",
"value": 2000
},
{
"id": 22,
"name": "max_heat_setpoint_limit",
"value": 30000
},
{
"id": 30,
"name": "running_mode",
"value": 4
},
{
"id": 41,
"name": "running_state",
"value": 1
},
{
"id": 16384,
"name": "comfort_heating_setpoint",
"value": 200
},
{
"id": 16385,
"name": "eco_heating_setpoint",
"value": 2800
},
{
"id": 16388,
"name": "valve_open_percentage",
"value": 5
},
{
"id": 16389,
"name": "boost_duration_seconds",
"value": 4294967294
}
]
},
{
"id": 516,
"name": "Thermostat User Interface Configuration",
"attributes": []
},
{
"id": 6,
"name": "On\/Off",
"attributes": []
},
{
"id": 1,
"name": "Power Configuration",
"attributes": []
}
]
}
],
"signature": {
"manufacturer": "_TZE200_b6wax7g0",
"model": "TS0601",
"node_desc": {
"logical_type": 2,
"complex_descriptor_available": 0,
"user_descriptor_available": 0,
"reserved": 0,
"aps_flags": 0,
"frequency_band": 8,
"mac_capability_flags": 128,
"manufacturer_code": 4098,
"maximum_buffer_size": 82,
"maximum_incoming_transfer_size": 82,
"server_mask": 11264,
"maximum_outgoing_transfer_size": 82,
"descriptor_capability_field": 0
},
"endpoints": {
"1": {
"profile_id": 260,
"device_type": 769,
"input_clusters": [
0,
4,
5,
61184,
513,
516,
6,
1
],
"output_clusters": [
10,
25
]
}
}
},
"class": "zhaquirks.tuya.ts0601_trv"
}
je ferai la demande à la fin du post.
