bonjour ,
serait-il possible d’intégrer le plafonnier eglo (awox) modele 900001
voici les informations brut
{
"ieee": "a4:c1:38:1a:84:ee:f1:7c",
"nwk": 8431,
"status": 2,
"lqi": "132",
"rssi": "-67",
"last_seen": "1645979978.3640304",
"node_descriptor": "01:40:8e:41:11:42:42:00:00:2a:42:00:00",
"endpoints": [
{
"id": 1,
"status": 1,
"device_type": 268,
"profile_id": 260,
"manufacturer": "AwoX",
"model": "TLSR82xx",
"output_clusters": [
{
"id": 6,
"name": "On\/Off",
"attributes": []
}
],
"input_clusters": [
{
"id": 0,
"name": "Basic",
"attributes": [
{
"id": 0,
"name": "zcl_version",
"value": 3
},
{
"id": 1,
"name": "app_version",
"value": 0
},
{
"id": 2,
"name": "stack_version",
"value": 2
},
{
"id": 3,
"name": "hw_version",
"value": 0
},
{
"id": 4,
"name": "manufacturer",
"value": "AwoX"
},
{
"id": 5,
"name": "model",
"value": "TLSR82xx"
},
{
"id": 7,
"name": "power_source",
"value": 1
},
{
"id": 16384,
"name": "sw_build_id",
"value": "0122052017"
}
]
},
{
"id": 3,
"name": "Identify",
"attributes": []
},
{
"id": 4,
"name": "Groups",
"attributes": []
},
{
"id": 5,
"name": "Scenes",
"attributes": []
},
{
"id": 6,
"name": "On\/Off",
"attributes": [
{
"id": 0,
"name": "on_off",
"value": 1
}
]
},
{
"id": 8,
"name": "Level control",
"attributes": [
{
"id": 0,
"name": "current_level",
"value": 254
}
]
},
{
"id": 768,
"name": "Color Control",
"attributes": [
{
"id": 3,
"name": "current_x",
"value": 0
},
{
"id": 4,
"name": "current_y",
"value": 0
},
{
"id": 7,
"name": "color_temperature",
"value": 333
}
]
},
{
"id": 4096,
"name": "LightLink",
"attributes": []
},
{
"id": 64599,
"name": "Manufacturer Specific",
"attributes": []
}
]
},
{
"id": 3,
"status": 1,
"device_type": 268,
"profile_id": 4751,
"manufacturer": null,
"model": null,
"output_clusters": [
{
"id": 65360,
"name": "Manufacturer Specific",
"attributes": []
},
{
"id": 65361,
"name": "Manufacturer Specific",
"attributes": []
}
],
"input_clusters": [
{
"id": 65360,
"name": "Manufacturer Specific",
"attributes": []
},
{
"id": 65361,
"name": "Manufacturer Specific",
"attributes": []
}
]
},
{
"id": 242,
"status": 1,
"device_type": 97,
"profile_id": 41440,
"manufacturer": null,
"model": null,
"output_clusters": [
{
"id": 33,
"name": "GreenPowerProxy",
"attributes": []
}
],
"input_clusters": []
}
],
"signature": {
"manufacturer": "AwoX",
"model": "TLSR82xx",
"node_desc": {
"logical_type": 1,
"complex_descriptor_available": 0,
"user_descriptor_available": 0,
"reserved": 0,
"aps_flags": 0,
"frequency_band": 8,
"mac_capability_flags": 142,
"manufacturer_code": 4417,
"maximum_buffer_size": 66,
"maximum_incoming_transfer_size": 66,
"server_mask": 10752,
"maximum_outgoing_transfer_size": 66,
"descriptor_capability_field": 0
},
"endpoints": {
"1": {
"profile_id": 260,
"device_type": 268,
"input_clusters": [
0,
3,
4,
5,
6,
8,
768,
4096,
64599
],
"output_clusters": [
6
]
},
"3": {
"profile_id": 4751,
"device_type": 268,
"input_clusters": [
65360,
65361
],
"output_clusters": [
65360,
65361
]
},
"242": {
"profile_id": 41440,
"device_type": 97,
"input_clusters": [],
"output_clusters": [
33
]
}
}
},
"class": "zigpy.device"
}
le debug
[2022-02-27 17:42:48]DEBUG : http://127.0.0.1:8089/device/command type : PUT
[2022-02-27 17:42:48]DEBUG : {"ieee":"a4:c1:38:1a:84:ee:f1:7c","cmd":[{"endpoint":1,"cluster":"on_off","command":"off","await":1}],"allowQueue":false}
[2022-02-27 17:42:48]DEBUG : {"devices":{"a4:c1:38:1a:84:ee:f1:7c":{"1":{"6":[{"value":"Bool.false","cluster_name":"On\/Off"}]}}}}
[2022-02-27 17:42:48]DEBUG : Search attribut for a4:c1:38:1a:84:ee:f1:7c logicalId : 1::6::0 => Bool.false convert to 0
[2022-02-27 17:42:50]DEBUG : http://127.0.0.1:8089/device/command type : PUT
[2022-02-27 17:42:50]DEBUG : {"ieee":"a4:c1:38:1a:84:ee:f1:7c","cmd":[{"endpoint":1,"cluster":"on_off","command":"on","await":1}],"allowQueue":false}
[2022-02-27 17:42:50]DEBUG : {"devices":{"a4:c1:38:1a:84:ee:f1:7c":{"1":{"6":[{"value":"Bool.true","cluster_name":"On\/Off"}]}}}}
[2022-02-27 17:42:50]DEBUG : Search attribut for a4:c1:38:1a:84:ee:f1:7c logicalId : 1::6::0 => Bool.true convert to 1
[2022-02-27 17:42:57]DEBUG : http://127.0.0.1:8089/device/command type : PUT
[2022-02-27 17:42:57]DEBUG : {"ieee":"a4:c1:38:1a:84:ee:f1:7c","cmd":[{"endpoint":1,"cluster":"light_color","command":"move_to_color_temp","await":1,"args":[67,0]}],"allowQueue":false}
[2022-02-27 17:42:58]DEBUG : {"devices":{"a4:c1:38:1a:84:ee:f1:7c":{"1":{"768":{"7":{"value":"153","cluster_name":"Color Control"}}}}}}
[2022-02-27 17:42:58]DEBUG : Search attribut for a4:c1:38:1a:84:ee:f1:7c logicalId : 1::768::7 => 153 convert to 153
[2022-02-27 17:43:00]DEBUG : http://127.0.0.1:8089/device/command type : PUT
[2022-02-27 17:43:00]DEBUG : {"ieee":"a4:c1:38:1a:84:ee:f1:7c","cmd":[{"endpoint":1,"cluster":"light_color","command":"move_to_color_temp","await":1,"args":[61,0]}],"allowQueue":false}
[2022-02-27 17:43:01]DEBUG : http://127.0.0.1:8089/device/command type : PUT
[2022-02-27 17:43:01]DEBUG : {"ieee":"a4:c1:38:1a:84:ee:f1:7c","cmd":[{"endpoint":1,"cluster":"light_color","command":"move_to_color_temp","await":1,"args":[26,0]}],"allowQueue":false}
[2022-02-27 17:43:04]DEBUG : http://127.0.0.1:8089/device/command type : PUT
[2022-02-27 17:43:04]DEBUG : {"ieee":"a4:c1:38:1a:84:ee:f1:7c","cmd":[{"endpoint":1,"cluster":"level","command":"move_to_level","await":1,"args":[192,0]}],"allowQueue":false}
[2022-02-27 17:43:05]DEBUG : {"devices":{"a4:c1:38:1a:84:ee:f1:7c":{"1":{"8":[{"value":"192","cluster_name":"Level control"}]}}}}
[2022-02-27 17:43:05]DEBUG : Search attribut for a4:c1:38:1a:84:ee:f1:7c logicalId : 1::8::0 => 192 convert to 192
[2022-02-27 17:43:05]DEBUG : http://127.0.0.1:8089/device/command type : PUT
[2022-02-27 17:43:05]DEBUG : {"ieee":"a4:c1:38:1a:84:ee:f1:7c","cmd":[{"endpoint":1,"cluster":"level","command":"move_to_level","await":1,"args":[101,0]}],"allowQueue":false}
[2022-02-27 17:43:07]DEBUG : {"devices":{"a4:c1:38:1a:84:ee:f1:7c":{"1":{"8":[{"value":"101","cluster_name":"Level control"}]}}}}
[2022-02-27 17:43:07]DEBUG : Search attribut for a4:c1:38:1a:84:ee:f1:7c logicalId : 1::8::0 => 101 convert to 101
le magasin physique où je l’ai acheter ATMOSPHERE BY EGLO
merci d’avance
