Bonjour à tous,
Je suis passé sous le dongle Popp et le plugin Zigbee pour utiliser tous mes capteurs Xiaomi.
J’en ai une vingtaine (capteurs d’ouverture, de luminosité, de vibrations, d’inondations…) et l’inclusion s’est passée sans encombre.
Par contre rien à faire pour le bouton aqara. Lors de l’inclusion il est repéré mais le process ne s’achève pas, la synchronisation ne se fait pas et il n’est pas pris en charge.
Comme si le plugin Zigbee ne prend pas en charge les modules « actionneurs » mais uniquement les « capteurs ».
Une idée?
Hello,
J’ai eu le même problème avant toi avec une récente version de deconz. Il y a un soucis avec la dernière version de deconz
opened 01:23PM - 22 Dec 21 UTC
closed 02:22PM - 08 Jan 22 UTC
Confirmed Bug
Bug report
## Describe the bug
The Aqara Smart Wireless Switch (WXKG11LM), which was easy … to add in previous version, can not be added anymore via Phoscon (see also #5585).
## Steps to reproduce the behavior
1. Go to 'Switches"
2. Click on 'Add Switch'
3. Click on 'Others'
4. Press the reset button of the switch for ~ 5 seconds
In deconz a new node was created, but in Phoscon nothing happens.
## Expected behavior
Pairing should work in Phoscon as it worked in the previous 2.12.06 version
## Screenshots
in Phoscon

in deconz


## Environment
- Host system: Fedora 35 (Raspberry Pi 4)
- Running method: deconz-community/deconz-docker podman container
- Firmware version: (26720700)
- deCONZ version: (2.13.04)
- Device: Conbee 2
- Do you use an USB extension cable: yey
- Is there any other USB or serial devices connected to the host system? If so: Which? - HardDisk
## deCONZ Logs
```
13:02:05:413 send permit join, duration: 65
13:02:19:315 0xFCFC nwk changed to 0xDEEA
13:02:19:316 device announce 0x00158D0006D4DEF5 (0xDEEA) mac capabilities 0x80
13:02:19:317 set fast probe address to 0x00158D0006D4DEF5 (0xDEEA)
13:02:19:317 FP indication 0x0000 / 0x0013 (0x00158D0006D4DEF5 / 0xDEEA)
13:02:19:317 ... (0x00158D0006D4DEF5 / 0xDEEA)
13:02:19:318 device announce 0x00158D0006D4DEF5 (0xDEEA) mac capabilities 0x80
13:02:19:336 DEV found DDF for 0x00158D0006D4DEF5, path:
13:02:19:344 FP indication 0x0104 / 0x0000 (0x00158D0006D4DEF5 / 0xDEEA)
13:02:19:345 ... (0x00158D0006D4DEF5 / 0xDEEA)
13:02:19:345 ZCL attribute report 0x00158D0006D4DEF5 for cluster: 0x0000, ep: 0x01, frame control: 0x18, mfcode: 0x0000
13:02:19:534 FP indication 0x0104 / 0x0000 (0x00158D0006D4DEF5 / 0xDEEA)
13:02:19:535 ... (0x00158D0006D4DEF5 / 0xDEEA)
13:02:19:536 Remember Xiaomi special for 0x00158D0006D4DEF5
13:02:19:537 ZCL attribute report 0x00158D0006D4DEF5 for cluster: 0x0000, ep: 0x01, frame control: 0x1C, mfcode: 0x115F
13:02:19:537 0x00158D0006D4DEF5 extract Xiaomi special attribute 0xFF01
13:02:19:538 01 battery 3145 (0x0C49)
13:02:19:539 03 Device temperature 29 °C
13:02:19:539 04 unknown 424 (0x01A8)
13:02:19:540 05 RSSI dB (?) 108 (0x006C)
13:02:19:540 06 LQI (?) 4294967296 (0x0100000000)
13:02:19:541 0a Parent NWK 60247 (0xEB57)
13:02:20:213 [1] get node descriptor for 0x00158d0006d4def5
13:02:20:214 ZDP get node descriptor for 0xDEEA
13:02:24:414 saved node state in 0 ms
13:02:24:415 sync() in 0 ms
13:02:24:889 FP indication 0x0000 / 0x8002 (0x00158D0006D4DEF5 / 0xDEEA)
13:02:24:889 ... (0x00158D0006D4DEF5 / 0xDEEA)
13:02:24:890 ZDP indication search sensors 0x00158D0006D4DEF5 (0xDEEA) cluster 0x8002
13:02:24:890 ZDP indication search sensors 0x00158D0006D4DEF5 (0xDEEA) clear timeout on cluster 0x8002
13:02:24:905 [2] get active endpoints for 0x00158d0006d4def5
13:02:24:906 ZDP get active endpoints for 0xDEEA
13:02:25:654 ZCL attribute report 0x00158D000774335F for cluster: 0x0201, ep: 0x01, frame control: 0x1C, mfcode: 0x1037
13:02:28:101 FP indication 0x0000 / 0x8005 (0x00158D0006D4DEF5 / 0xDEEA)
13:02:28:102 ... (0x00158D0006D4DEF5 / 0xDEEA)
13:02:28:102 ZDP indication search sensors 0x00158D0006D4DEF5 (0xDEEA) cluster 0x8005
13:02:28:103 ZDP indication search sensors 0x00158D0006D4DEF5 (0xDEEA) clear timeout on cluster 0x8005
13:02:28:115 [4] Skipping additional attribute read - Model starts with 'lumi.'
13:02:31:683 Bind response success for 0x00158d000774335f ep: 0x01 cluster: 0x0001
```
J’espère que ça peut aider.
edit : oups, j’avais pas lu que tu utilisais popp+zigbee. désolé.
1 « J'aime »
Mikael
Février 2, 2022, 6:36
3
Hello
Si je peux me permettre et si vous avez la possibilité passé par
Simple rapide sans prise de tête.
Et pour info
pauzD
Février 17, 2022, 7:47
4
Ca y est j’ai réussi à l’inclure après de très nombreuses tentatives. Pour une raison inconnue il a fini par être inclus.
